4.6 TPMS Diagnostics
The Diagnostics function is used to check the status of the TPMS system. This function
requires connection with the test vehicle. Refer to Establishing Vehicle Communication
on page 50 for details.
➢ To perform TPMS diagnostics function
1. Tap the Diagnostics tab. The tablet will automatically communicate with the
vehicle.
Figure 4-16 Diagnostics Communication Screen
2. The diagnostics results will be displayed on the screen automatically.
Figure 4-17 Diagnostics Screen 1
