AVC Technology H.264 - Alarm-Out; SPOT-OUT Setup

24
3-4-1. ALARM-OUT
Figure 3.4.2. ALARM-OUT setup screen
Table 3.4.2. Menu item in ALARM-OUT Setup screen
Item Description
ALARM OUT
Available NO is just one (1).
SENSOR IN
Enable setting up to 1 camera of 4 cameras for each alarm.
MOTION ON
Enable setting up to 1 camera of 4 cameras for each alarm.
VIDEO LOSS ON
Enable setting up to 1 camera of 4 cameras for each alarm.
ALARM DURATION
Set the alarm dwell time from 5 to 60 seconds.
ERROR ALARM
Set the error type for the alarm activation. The options are
OFF, ALL, HDD ERROR and VIDEO LOSS.
3-4-2 SPOT-OUT setup
Figure 3.4.3. SPOT-OUT setup screen
Table 3.4.3. Menu item in SPOT-OUT Setup screen
Item Description
