AVC Technology H.264 - Search and Playback Window; Main User Interface

To Next Page

To Previous Page

User can control PAN/TILT & ZOON/FOCUS.

PAN left /right TILT up/down

ZOOM in/out FOCUS in/out

CHANNEL SPLIT

To select the numbers of display channel/channels (Single,

quad, 9 channels, and 16 channels) of highlighted site.

DVR SITE SPLIT

To select the numbers of DVR/DVRs (1 DVR, 4 DVRs, 9 DVRs,

16 DVRs) on main display screen.

9-5. Search and Playback Window

9-5-1. Main user interface

You can access to search window by clicking the search icon (Local Playback / Remote Playback) on the

upper left of Live Window.
