Table 4.3.1. Button functions in PLAY Mode
Button Description
Return to the previous menu screen, search window, or exit from the
Menu
◀◀
◀◀◀◀
◀◀
Press to rewind the footage at 1x, 2x, 4x, and 8x speeds. Reverse
playback speed is shown as -1x(normal), -2x (2 times normal), -4x (4
times normal), and -8x (8 times normal) at the bottom right of the
screen.
--
----
--◀
◀◀
◀
Jump/Step backward.
The playback position moves 60 seconds backward.
▶
▶▶
▶/
/ /
/ II
Press to play or pause recorded video.
▶
▶▶
▶--
----
-- Jump/Step forward. Playback position moves 60 seconds forward.
▶▶
▶▶▶▶
▶▶
Press to fast forward the footage at 1x, 2x, 4x, and 8x speeds.
Playback speed is indicated as +1x, +2x, +4x, and +8x for normal,
twice, 4 times, and 8 times of the regular speed at the bottom right of
the screen.
Press to backup the video.
5. PTZ Control
To control the PTZ functions of the camera, select PTZ menu on the screen using the mouse. Select the
item you wish to control the PTZ camera and control them using the control button (◀ ▲ ▶ ▼).
Please refer to the table 5.1. for the control.
Table 5.1. Button Functions in PTZ Control
Item Description
INITIALIZE
Initialize the PTZ settings of the selected camera.
PAN / TILT
Select PAN/TILT using the control button (◀ ▲ ▶ ▼)
and press SEL button.
Adjust the tilt(UP/DOWN) / pan(LEFT/RIGHT) position
using the control button (◀ ▲ ▶ ▼).
ZOOM /
FOCUS
Select ZOOM/FOCUS using the control button (◀ ▲ ▶
▼) and press SEL button.
Adjust the zoom(UP/DOWN)/focus(LEFT/RIGHT)position
using the control button(◀ ▲ ▶ ▼).
OSD
Select the OSD to enter the menu. Control keys are
Right, Left, UP, Down, Select, Far (REW KEY), and Near
