Installation and Setup 9
Updating S3 Firmware
After installing EuControl, make sure your S3 is running the latest firmware. The firmware is provided within EuControl, so an In-
ternet connection is not required.
To update S3 firmware:
1 Click (Mac) or double-click (Windows) the EuControl icon and select EuControl Settings.
2 If necessary, click Surfaces to display the Surfaces tab.
3 Click Avid S3 in the My Surfaces list so it is highlighted.
4 Click Update Firmware. If the Update Firmware dialog shows a message that the surface is up to date, no further action is nec-
essary.
5 If the firmware needs to be updated, follow the instructions in the Update Firmware dialog box to proceed, and make sure to ob-
serve the following guidelines when updating firmware:
• Ensure that S3 is connected to a trustworthy power source.
• Do not power off the S3 during the update or attempt to interrupt the update.
The status of the firmware update is shown on the S3 displays as well as in the EuControl dialog.
6 Click Done when the firmware update is complete, then proceed to Enabling EUCON in Pro Tools.
Surfaces tab
If S3 does not appear in the My Surfaces list, add it manually. See Add.
