Avid Technology Pro Tools S3 User Manual

Audio Specifications 66
S3 Analog Mic Inputs, Pad Enabled
Parameter Conditions
Value
Units
Min. Typ. Max.
Phantom Power
48 Volts
Input Sensitivity
@ 997Hz, Gain = 10 dB (min.)
+28.322 dBu
Frequency Response V
INPUT
=+8.225 dBu, 20 Hz – 20 kHz relative to
1 kHz, Gain = 10 dB (min.)
-0.016 0 -0.235 dB
Dynamic Range Unweighted
150  source impedance, Gain = 10 dB (min.)
-111.2 dB
Dynamic Range A Weighted
150  source impedance, Gain = 10 dB (min.)
-113.9 dB
THD+N Amp @ 997 Hz, Gain =40 dB
0.0018 %
THD+N Freq measured at -3.808 dBu, 20 Hz – 20 kHz,
Gain = 40 dB
0.0012 0.0018 0.0064 %
Common Mode Rejection Ratio V
INPUT
= -1.276 dBu, 20 Hz – 20 kHz,
Gain = 20 dB
-59.3 -63.8 -63.9 dB
Inter-Channel Crosstalk V
INPUT
= +8.233 dBu, 20 Hz – 20 kHz,
Gain = 10 dB (min.)
-122.1 -109.1 -98.2 dB
Input Impedance @1 kHz
3.7k ohms
S3 Analog Line Inputs
Parameter Conditions
Value
Units
Min. Typ. Max.
Input Sensitivity @ 997Hz, Gain = 10 dB (min.)
+18.471 dBu
Equivalent Input Noise (EIN)
Gain = 18 dB, 150source impedance
-93.9 dB
Frequency Response V
INPUT
=-1.520 dBu, 20 Hz – 20 kHz relative to
1 kHz, Gain = 10 dB (min.)
-0.018 0 -0.233 dB
Dynamic Range Unweighted
150  source impedance, Gain = 10 dB (min.)
-110.4 dB
Dynamic Range A weighted
150  source impedance, Gain = 10 dB (min.)
-113 dB
THD+N Amp @ 997Hz, Gain =40 dB
0.0010 %
THD+N Freq measured at +12.193 dBu, 20 Hz – 20 kHz,
Gain = 40 dB
0.0005 0.0010 0.0016 %
Common Mode Rejection Ratio V
INPUT
= -1.523 dBu, 20 Hz – 20 kHz,
Gain = 0 dB
-64.4 -66.8 -67.0 dB
Inter-Channel Crosstalk V
INPUT
= -1.520 dBu, 20 Hz – 20 kHz,
Gain = 0 dB (min.)
-117.8 -110.1 -98.3 dB
Input Impedance @1 kHz
5.1k ohms
