12-6 System Updates
When downloaded to the USB fob, the data logs will be saved in
.csv files. This can be imported into newer versions of Microsoft
Excel into a table format. The data can then be plotted or
analyzed by several 3
rd
party tools. Note that files can easily
contain 50MB or more of data.
Data included in the files are as follows:
System Log
Date/Time stamp Vertical Speed bug setting
Power On Display mode
OAT Nav mode
Autopilot mode GPSS state
Localizer deviation OBS value
Glideslope deviation Desired track
Ground speed Nav frequency
Ground track Course select value
Crosstrack deviation Nav type
Vertical deviation VOR course
Baro setting GPS altitude
Altitude bug setting Distance to active waypoint
Heading bug setting FMS course
Flight Log
Date/Time stamp Flight director status and commands
Power on Turn rate
Accelerations Pressure altitude
AHRS status Indicated airspeed
Heading True airspeed
Pitch Vertical speed
Roll Lat/Lon
