PROGRAMMING MENUS
Meter Setup Menu
Meter Setup
Calibration Diameter
[Diameter]
A
Factory set. In the event the amplifier is replaced, verify that the pipe
diameter matches the installed pipe size.
Detector Factor
[Det Fact]
A
Factory set. Compensates for accuracy error as a result of the
installeddetector.
In the event the amplifier is replaced, this parameter must be
reprogrammed with the original detector factor.
Detector Zero
[Det Zero]
A
Factory set. Compensates for accuracy error as a result of the
installeddetector.
In the event the amplifier is replaced, this parameter must be
reprogrammed with the original detector zero.
Amplifier Factor
[Amp Fact]
Read only
Factory set and Read Only. Compensates for accuracy error as a result of
the installed amplifier.
Coil Current
[Coil Cur]
Read only
Factory set and Read Only. Compensates for accuracy error as a result of
the installed amplifier.
Scale Factor
[Scale]
S
Changing the scale factor lets you adjust the meter´s accuracy without disturbing parameters set
by the factory. You can tune the meter to meet changing application requirements.
Can be adjusted in the range 0.901…1.0999.
Power Line Frequency
[Freq HZ]
60 Hz
S
Provides measuring immunity to industrial noise from a power supply
feed. It is factory set to 60 Hz, which is the value used in the US.
50 Hz Optional setting. 50 Hz is the value used outside the US.
Period
[Period s]
A
This parameter configures the frequency to 0…63 seconds of sampled measurements.
The adjustment can be done in steps of 1 second. The value 0 is only used for calibration (4
measurements per second).
OTE: N Parameters indicated by the battery icon affect battery performance. Standard sampling
period is 15 seconds.
Empty Pipe Detection Empty Pipe ON/OFF
[On Off]
S
When set to ON, an Empty Pipe condition indicates to the outputs
that the meter is not completely filled. When set to OFF, empty pipe
conditions are not detected.
Threshold
[Threshold]
S
Factory set and adjusted to the conductivity of normal water.
Measure
[Measure]
Read only
Measures the real empty pipe value, Read Only.
Programming Menus
MAG-UM-00219-EN-17Page 30 June 2021
