Communication Menu
Communication: Port Settings
Interface
[Interface]
S
Provides communication port configuration.
• IrDA (Modbus RTU)
• Serial (Modbus RTU)
OTE: N Modbus RTU is only for programming the meter or reading the internal data logger. Extended
use, even in standby mode, uses power and can drain the battery quickly.
• M-Bus
• OFF (turns off the serial interfaces). Serial interfaces left ON shorten the battery life.
Serial
[Serial]
Baud Rate
[Baudrate]
S
Sets the baud rate.
The following baud rates are supported:
• 9600 (Default)
• 1200
• 2400
Parity
[Parity]
S
Sets the parity.
The following parities are supported:
• Even (Default)
• Odd
• Mark
Modbus
[Modbus]
Address
S
Configures the Modbus address in the range of 1…247. See the "M-5000
Modbus Communication Protocol Memory Map" application data sheet
(available at www.badgermeter.com) for Modbus register information.
M-Bus
[M-Bus]
Address
S
Configures the M-Bus® address in the range of 1…247.
ADE Control ON/OFF
Protocol
[Protocol]
V1 standard messages
V2 extended messages
Dial
[Dial]
4…9
Resolution
[Resolution]
0.0001…10000
Programming Menus
MAG-UM-00219-EN-17 Page 35 June 2021
