Badger Meter ModMAG M5000 User Manual

Detector Type VI
Size 1/2…24 in. (DN 15…600)
Process Connection
Flange Type DIN, ANSI, JIS, AWWA and more
Material Standard: carbon steel; optional: stainless steel 304/316
Pressure Limits Up to 1450 psi (100 bar) PED
Meter Enclosure Classification Standard: NEMA 4X (IP67); Optional: Submersible NEMA 6P IP68, remote amplifier required
Minimum Conductivity ≥20 µS/cm
Liners Material Available for sizes Fluid Temp for Remote Mount Fluid Temp for Meter Mount
PTFE 1/2…24 in. (DN 15…600) 302° F (150° C) 212° F (100° C)
Hard rubber 1…24 in. (DN 25…600) 178° F (80° C) 178° F (80° C)
Electrode Materials Standard: Hastelloy® C; optional: Tantalum, Platinum/Gold plated, Platinum/Rhodium, 316 stainless steel
Meter Housing Material Standard: Carbon steel painted; optional: Stainless steel 304/316 or painted in C5M
Optional Stainless Steel
Grounding Rings
ANSI Flanges All Other Flanges
Meter Size Thickness (of 1 ring)
1/2…1 in. (DN 15…25) 0.135 in. (3.42 mm)
12…24 in. (DN 300…600) 0.187 in. (4.75 mm)
Meter Size Thickness (of 1 ring)
1/2… 24 in. (DN 15…600) 0.12 in. (3 mm)
Remote Version
in. (mm)
Mounted Version
in. (mm)
A
4.80 (122)
3.15 (80)
B1
C1
4.72 (120)
K
D
d2 x n
M5000-3
DN
3.90 (99)
7.09 (180)
7.09 (180)
M20 (x4)
11.06 (281)
2.36 (60)
Ø0.20 (5.2)
2.56 (65)
A
B2
C2
K
D
d2 x n
DN
M5000-2
7.09 (180)
7.09 (180)
3.27 (83)
M20 (x4)
Size
in.
(DN)
A Std*
in.
(mm)
A ISO**
in.
(mm)
B1
in.
(mm)
B2
in.
(mm)
C1
in.
(mm)
C2
in.
(mm)
with ANSI-flanges with DIN-flanges
ø D
in.
(mm)
ø K
in.
(mm)
ø d2×n
in.
(mm)
ø D
in.
(mm)
ø K
in.
(mm)
ø d2×n
in.
(mm)
1/2
(15)
6.7
(170)
7.87
(200)
9.37
(238)
11.73
(298)
13.9
(351)
13.4
(342)
3.5
(88.9)
2.37
(60.3)
0.63 × 4
(15.9 × 4)
3.75
(95)
2.56
(65)
0.55 × 4
(14 × 4)
3/4
(20)
6.7
(170)
7.87
(200)
9.37
(238)
11.73
(298)
14
(356)
13.6
(347)
3.9
(98.4)
2.75
(69.8)
0.63 × 4
(15.9 × 4)
4.13
(105)
2.95
(75)
0.55 × 4
(14 × 4)
1
(25)
8.9
(225)
7.87
(200)
9.37
(238)
11.73
(298)
14.2
(361)
13.8
(352)
4.3
(107.9)
3.13
(79.4)
0.63 × 4
(15.9 × 4)
4.53
(115)
3.35
(85)
0.55 × 4
(14 × 4)
1-1/4
(32)
8.9
(225)
7.87
(200)
9.96
(253)
12.32
(313)
15
(381)
14.6
(372)
4.6
(117.5)
3.50
(88.9)
0.63 × 4
(15.9 × 4)
5.51
(140)
3.94
(100)
0.71 × 4
(18 × 4)
1-1/2
(40)
8.9
(225)
7.87
(200)
9.96
(253)
12.32
(313)
15.2
(386)
14.8
(376)
5.0
(127)
3.87
(98.4)
0.63 × 4
(15.9 × 4)
5.91
(150)
4.33
(110)
0.71 × 4
(18 × 4)
2
(50)
8.9
(225)
7.87
(200)
9.96
(253)
12.32
(313)
15.7
(398)
15.3
(389)
6.0
(152.4)
4.75
(120.6)
0.75 × 4
(19 × 4)
6.50
(165)
4.92
(125)
0.71 × 4
(18 × 4)
Specications
MAG-UM-00219-EN-17 Page 47 June 2021
