Battery Menu
PwrUpCnt
(Read Only)
(Power Up Counter) A diagnostic counter of how many times the meter has reset or been power cycled
(for instance, battery removed and replaced).
Voltage
(Read Only)
Displays the current battery voltage.
Lifetime
(Read Only)
Displays the remaining battery life time in years depending on the currently selectedparameters.
OTE: N Battery life time is mainly influenced by the excitation frequency (period) and selected
communication interfaces.
OnTime
(Read Only)
Diagnostic that refers to the amount of time the meter has been powered in terms ofhours.
Capacity
[Bat Ah]
(Read Only)
Displays the current battery capacity in Amp hours or Percent.
OTE: N A new battery should be at or near maximum capacity.
Limit
S
Options: 5, 10, 15, 20,
25, 30, OFF
Sets the battery capacity remaining threshold that generates an output alarm
when the remaining battery capacity drops below the threshold. Set to OFF if
output alarm is not needed.
Change
S
Options: 19, 38, 70, Ah Allows the user to change the battery through a controlled process. The user
selects the new battery pack capacity and then is required to replace the
battery. While in entry mode, exit from this menu item is prohibited until
after the battery is replaced. Additionally, this is the required process to save
necessary measurement data to non-volatile memory while also resetting
all battery configuration and diagnostic data (such as lifetime, capacity
remaining, saved totalizers).
Programming Menus
MAG-UM-00219-EN-17Page 36 June 2021
