Badger Meter ModMAG M5000 User Manual

Measure Menu
Measure
Flow Unit
[Flow Unit]
U
Establishes the unit of measure for the flow rate and full scale flow. Changing this parameter readjusts
the full scale flow parameter. For example, changing from GPM to GPS would change the full scale flow
from 60 gal/min to 1 gal/s.
Display Flow Unit Display Flow Unit
LPS Liters/Sec. GPS Gallons/Sec.
LPM Liters/Min. GPM Gallons/Min.
LPH Liters/Hour GPH Gallons/Hour
M3S Cubic Meters/Sec. MGD MillionGallons/Day
M3M Cubic Meters/Min. IGS ImperialGallons/Sec.
M3H Cubic Meters/Hour IGM ImperialGallons/Min.
F3S Cubic Feet/Sec. IGH ImperialGallons/Hour
F3M Cubic Feet/Min. OPM Ounce/Min.
F3H Cubic Feet/Hour BPM Barrel/Min.
Totalizer Unit
[Tot Unit]
U
Establishes the units of measure for the totalizers.
Display Totalizer Unit
L Liters
HL Hectoliter
M^3 Cubic Meters
CFt Cubic Feet
USG US Gallons
MG Million Gallons
UKG Imperial Gallons
Oz Fluid Ounces
Aft Acre foot
BBL Barrel (42 gallons)
Full Scale Flow
[Full Sca]
S
Sets the maximum flow the system is expected to measure. Influences other system
parameters,including:
• Low Flow Cutoff – Changes to full scale flow affect the measuring cut-off threshold of the meter
• Alarm Outputs – Changes to full scale flow adjusts the thresholds for generating setpoint alarms
• Pulse Outputs – Changes to full scale flow adjusts the pulse frequency and duty cycle
Change the full scale flow based on the meter size and the application’s requirements. Verify that the
full scale flow falls within the meter’s suggested flow range limits.
Flow Range: 0.1…32.8 ft/s (0.03…10 m/s)
The full scale flow is valid for both flow directions.
OTE: N If the flow rate exceeds the full scale setting by more than 25%, a FLOW_OVERLOAD_WARNING
message indicates that the configured full scale range has been exceeded. The meter continues
to measure. This affects the latency of the pulse outputs and may causeoverflow.
Low Flow Cutoff
[Cut Off]
U
Defines the threshold at which flow measurement is forced to zero. The cutoff value can be set from
0…9.9% of the full scale flow. Increasing this threshold helps prevent false readings during “no flow”
conditions possibly caused by pipe vibration or inherent system noise.
Programming Menus
MAG-UM-00219-EN-17 Page 31 June 2021
