Badger Meter ModMAG M5000 User Manual

Measure
Flow Direction
[Bi-directional]
S
Allows setting the meter to measure forward flow only (unidirectional) or both forward and reverse
flow(bidirectional).
Unidirectional
Flow is totalized in only one direction. The flow direction is indicated by the arrow printed on the
detector label. Unidirectional measurements on the main display screen include:
T1: Registers forward flow, resettable by menu or Modbus RTU.
T2: Registers forward flow, non-resettable.
Bidirectional
Flow is totalized in both directions. A change of flow direction can be indicated by the digital output.
Bidirectional measurements on the main display screen include:
T1+: Registers forward flow, resettable by menu or Modbus RTU
T1-: Registers reverse flow, resettable by menu or Modbus RTU
T1N: Registers total flow, T+ - T-, resettable by menu or Modbus RTU
T2+: Registers forward flow, non-resettable
T2-: Registers reverse flow, non-resettable
T2N: Registers total flow, T+ - T-, non-resettable
T1 Reset
[T1]
S
Allows the reset of totalizer T1.
OTE: N If the meter is used as a water meter according the European directive 2004/22/EC (MID
MI-001) or OIML R49, then the totalizer T1 is non-resettable.
Median
[Median]
Can be set to ON or OFF. When set to ON, the median display filters out the flow rate fluctuations
displayed on the LCD.
Average
[Average]
Known as a measurement averaging filter. The user can select how many flow rate measurements to be
averaged together to calculate the current flow rate value. Dampens the rate of change of the flowrate.
Moving average filter (MAV) smooth out short-term fluctuations. The value can be adjusted from 1 to 20
measuring periods.
The delay is calculated: Delay [s] = MAV x T
The time T is given by the adjusted excitation frequency (period) of the meter.
For example MAV = 2 and the excitation frequency (period) is T = 5 s means a delay of 10 s.
Filter Display
[FiltDisp]
Can be set from 0…99 seconds. The display updates less frequently, depending on how high the filter
display is set.
