Logging In
To change any parameter in the mag meter, the PIN entered must provide the proper security privilege required by
the parameter.
To enter a PIN, go to the Login menu and enter the PIN for the required security level. Once you are properly logged in, the
unlocked icon appears on the meter display. A PIN Error message displays if the incorrect PIN is entered.
Logging Out
To log out, follow steps 1 through 8 under "Setting a PIN". At step 9, enter an invalid PIN, then press EXIT SAVE.
PIN Menu
PIN
Control
A
Two options are available:
• ON (requires PIN configuration)
• OFF
User
U
Users logged in with this PIN have access to all user levels. Users at this level do not have access to
Service or Admin functions.
Service
S
Users logged in with this PIN have access to both service and user-level procedures. Users at this level
do not have access to Admin functions.
Admin
A
Users logged in with this PIN have access to all procedures. Users at this level have full access to
themeter.
Random Generates a random number which is used when a PIN is lost. This number is needed for Badger Meter
Tech Support to provide a Master PIN.
Emergency Enter the Master PIN received from Badger Meter Technical Support to unlock the meter in case the
Admin PIN has been lost.
Security
MAG-UM-00219-EN-17Page 40 June 2021
