Inputs/Outputs
Digital Outputs
(continued)
Set Minimum
[Set Min]
S
Establishes, as a percentage of full scale flow, the threshold at which the output
alarm is activated. Flow rates below the threshold activate the output alarm.
Set Maximum
[Set Max]
S
Establishes, as a percentage of full scale flow, the threshold at which the output
alarm is activated. Flow rates above the threshold activate the output alarm.
Function
[Out 1 Func]
[Out 2 Func]
[Out 3 Func]
[Out 4 Func]
S
Provides configuration of the functional operation of the associated output. The
following operations are supported:
Function Dig1 Dig2 Dig3 Dig4
Off X X X
Test X X X
MinMax X X X
Empty X X X
ErAlarm X X X
Forward X
Reverse X
Direct X
ADE X
• Inactive [Off] means digital output is switched off. It is recommended
to switch off the outputs in the menu “Output function” if not used. This
increases the battery life time.
• Test [Test] triggers the output.
• Flow setpoint [MinMax] provides indication when flow rate exceeds
thresholds defined by flow setpoints (set min, set max).
• Empty pipe alarm [Empty] provides indication when pipe is empty.
• Error alarm [ErAlarm] provides indication when meter has error condition.
• Forward pulse [Forward] generates pulses during forward flow conditions.
• Reverse pulse [Reverse] generates pulses during reverse flow conditions.
• Flow direction [Direct] provides indication on current flow direction.
• ADE [ADE] “Absolute Digital Encoder” for remote meter reading using ASCII
communication protocol.
Output Mode
[Out 1 Type]
[Out 2 Type]
[Out 3 Type]
[Out 4 Type]
S
Allows you to set the output switch to normally open or normally closed. If
normally open is selected, the output switch is open (no current) when the
output is inactive, and closed (current flows) when the output is active.
If normally closed is selected, the output switch is closed (current flows) when
the output is inactive, and open (no current) when the output is active.
