Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
MSI Set
Length 1
This feature specifies one of the barcode lengths for MSI Length Control. Length 1 is the mini-
mum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Length includes the barcode’s data characters only. The length can be set from 01 to 50 charac-
ters.
Table MSI Length 1 Setting Examples provides some examples for setting Length 1. See
page 249 for detailed instructions on setting this feature.
MSI Length 1
Setting
Examples
STEP ACTION EXAMPLES
1 Desired Setting
01
Characters
07
Characters
15
Characters
50
Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT MSI LENGTH 1 SETTING
4
Scan Two Characters
From Appendix D:
Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select MSI Set Length 1 Setting
Make a mistake? Scan the CANCEL barcode
to abort and not save the entry string. You
can then start again at the beginning.
CANCEL
$CMSL1
~
DEFAULT
01 = Length 1 is 1 Character
