Setup
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Attaching the
Metal Plate to
Base
Alternatively, the mount can be attached first to the base, then both can be mounted to a wall as
described above.
Figure 5: Attaching Mounting Plate to Base
2.4.4 System
Connections
The Base station cradle provides a multi-interface connector and a power supply connector as
shown:
Base with Mount attached
CAUTION
Connections should always be made with power off!
Power Supply
Multi-Interface Connector
