240
4
References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
ACK NAK
Options
This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. When
configured, the reader and/or host sends an “ACK” when it receives data properly, and sends
“NAK” when the data is in error.
Options are:
-Disable
- Enable for label transmission — The reader expects an ACK/NAK response from the host
when a label is sent.
- Enable for host-command acknowledge — The reader will respond with ACK/NAK when the
host sends a command.
- Enable for label transmission and host-command acknowledge
ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII
characters or any hex value from 0 to 0xFF can be selected.
1 Determine the desired character or value.
2 Use the ASCII Chart on the inside back cover of this manual to find the hex equivalent for the
desired character/value.
3 Go to page 40 and scan ENTER/EXIT PROGRAMMING MODE to enter Programming Mode.
4 Scan the barcode: SELECT ACK CHARACTER SETTING.
5 Scan the appropriate two alphanumeric characters from the keypad in Appendix D: Keypad,
that represent the desired character/value in step 1 above. The second character will cause a
two-beep indication.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit.
See Table ACK Character Setting Examples for some examples of how to set this feature.
ACK Character
Setting
Examples
NOTE
Setting to previously defined characters such as XON, XOFF, or host com-
mands conflicts with normal operation of these characters. 8-bit data is not rec-
ognized when the option Data Bits has been set as 7 Data Bits.
STEP ACTION EXAMPLES
1
Desired Character/
Value
ACK $ @ >
2
Hex equivalent from
Fig.
10 ASCII Chart
ASCII Chart
0x06 0x24 0x40 0x3E
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT ACK CHARACTER SETTING
5
Scan Two Characters
from
Appendix D:
Keypad
‘0’ and ‘6’ ‘2’ and ‘4’ ‘4’ and ‘0’ ‘3’ AND ‘E’
6 Scan ENTER/EXIT PROGRAMMING MODE
