Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Stand Mode
Sensitivity
Sets the sensitivity level for stand mode wakeup. Choices are low, medium and high.
Stand Mode
Illumination Off
Time
Specifies the amount of time reader illumination stays off after pulling the trigger when in Stand
Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds).
See
page 262 in “References” for a description of this feature.
Stand Mode Sensitivity = Low
Stand Mode Sensitivity = Medium
Stand Mode Sensitivity = High
$CSMSE00(C
$CSMSE01(C
DEFAULT
$CSMSE02(C
Select Stand Mode Time Setting
To configure this feature, scan the ENTER/
EXIT PROGRAMMING MODE barcode
above, then the barcode at left followed by
the digits from the Alphanumeric characters
in
Appendix D: Keypad representing your
desired character(s). End by reading the
ENTER/EXIT barcode again.
$CSNTM
DEFAULT
04 = 2 Seconds
