Barco DP2K-E series

13. Lamp House
3
3
3
Image 13-3
5. Remove the Lamp Module as follows:
a) Grip the Lamp Mo dule by the handle (4) and slide it out half way of the lamp com partment.
b) Support the Lamp Module at the bottom with the other hand and remove it from the lamp com partment.
c) Place the Lamp Module on a s table support.
3
3
3
4
Image 13-4
102 R5906693 DP2K-E SERIES 19/06/2015
