8. ICMP
8.5 ICMP reset button an d status LEDs
ICMP status LEDs and Reset button
LEDs on ICMP front pa nel give information on the status of the de vice.
1
2
3
Image 8-8
Status overview PWR/ERRO R and RE ADY LE Ds:
1 2
PWR/ERROR READY ICMP Status
Off Off Turned off
Red
Off
Board res et
Blinking Green Off Boot loader
Blinking Green Blinking O range Operating System start up
Blinking Green Orange Security Manager - Image Integrity tests
Blinking Green Blinking Yellow Security Manager - Self Test
Blinking Green
Yellow
Security Manager - FPG A self-test
Green Blinking Orange
Update ongoing
Green Blinking Green FIPS o k - A pplication startup
Green Green Power on & No Error
Blinking Red
Off FIPS error
3
Reset button
Button used to reset ICM P ( reference 3 imag e 8-8)
CAUTION: It is not recommended to use the ICMP reset button if conventional means to stop and restart the
ICMP a re always available. It is an ultimate resort in the event of co mp lete b lockage of interface.
CAUTION: In case the ICM
P is installed in a RGB -laser illuminated cin ema projector it is reco mmen ded to put
the lasers in deconditioning state before pressing the reset button and condition them again from the moment
the ICMP is rebooted (after reset). Reset ting the ICMP with lasers on can create a risk as the p roper operation
of the DMD cooling ca
nnot be g uaranteed in this case.
58 R5906693 DP2K-E SERIES 19/06/2015
