16. Removal and installation of the projector covers
16.7 Removal of the side cover plate of t he Light Processor compartment
To access the side cover plate o f the Light Processor compartment, the projector left side cover must first be
removed. This procedure assumes that the projector left side cove r is already removed.
CAUTION: Op ening the Light Processor com partm ent by removing the top cover plate or side co ver plate w i
ll
result in a tam per event. An authorization to clear the security warn ing on the projector, af ter closing off the
Light Processor compartmen t, will be n eeded !
Necessary tools
3 m m Allen wrench.
How to remove the side cover plate from the Light Processor compartment?
1. Remove the four screws at the top of the cover plate and the two screws at t he bottom of the cover plate (reference 1, image 16-9).
Use a 3 mm Allen wr ench.
2. Slide the s ide cover plate left to disengage the cover, and then remove it.
1
1
Image 16-9
R5906693 DP2K-E SERIES 19/06/2015 127
