Barco DP2K-E series User Manual

16. Removal and installation of the projector covers
16.8 Installation of the side cover plate of the Light Processor compartment
Necessary tools
3mmAllenkey.
How to install the side cover plate from the Light Processor compartment?
1. Place the side cover plate into position and slide to the right until all slots of the side cov er plate are correctly engaged.
1
1
Image 16-10
2. Fasten the s ide cover plate into place with four screws at the top and two screws at the bottom (reference 1, image 16-10). Use
a3mmAllenkey.
CAUTION: Op ening the Light Processor com partm ent by removing the top c over p late or side cover plate will
result in a tam per event. An authorization to clear the security warn ing on the projector, af ter closing off the
Light Processor compartmen t, will be n eeded !
128 R5906693 DP2K-E SERIES 19/06/2015
