8. ICMP

8.3 ICMP communication ports

Location of the communication ports

1 2 3 4 5 6 7

Image 8-6

Functionality

AUDIO-AES 1-8 (9-16)

ICMP o utputs sixteen audio signals equitably distributed over these two RJ45 connectors, which can be conﬁgured

independently. The mapp ing o f audio channels (content) on each audio output (AES outputs of the ICMP) is performed by

conﬁguring the ICMP via the Com munic ator software. Plea

se refer to the Communicator user guide for further information.

GPO 1-4 (5-8 )

These RJ45 c onnectors can be use d to send trigger signals to other devices. The mapping of user Cues (o utput Cues) on

each G eneral Purpose Output (GPO) is conﬁguredviatheComm

unicator software. Please refer to the C om municator

user guide for further information.

GPI 1-4 (5-8)

These RJ45 connec tors c an be used t o receive trigger signals

from other devices. The mapping of the G enera l Purpose

Input (G PI) on each input Cues is conﬁ gur ed via the Comm unicator software. Please refer to the Commun icator user

guide for further information.

SYNC IN / OUT

Synchronization signal IN and OUT: R eserved for multiple-projector projection. Use a 50 Ohm c oaxial cable to connect

the sync signal from projector to projector.

LAN 1 (2)

The ICMP can be connected to a LAN (local area network) using one of the Ethernet ports. These LA N port are used

for ‘content’ transfer.

NOTE: These ports are optionally used to connec t to external content storage sources. Control of the ICMP is done via the

same IP address as the projector.

USB 2.0

The ICMP can be connected to a USB 2.0 M edia to load content. The USB port can be used to load content (DCP) or

keys (K DM).

NOTE: It is recommended to use the US B 3.0 ports for f aster ingest.

USB 3.0

The ICMP c an be connected to a U SB 3.0 Media to load content. The USB port can be used to load content (DCP ), o r

keys (KDM), or software update.

NOTE: These por ts are recommended for fast ingest when connected to an appropriate USB 3.0 source.

R5906693 DP2K-E SERIES 19/06/2015
