18. Pin configurations
GPO 5-8
Definition
RJ-45 pin
EXT_GPOU T_6_P
3
EXT_GPOU T_6_N
4
EXT_GPOU T_7_P
5
EXT_GPOU T_7_N
6
EXT_GPOU T_8_P
7
EXT_GPOU T_8_N
8
General Purpose Input:
GPI 1-4
Definition RJ-45 pin
EXT_GPIN_1_P 1
EXT_GPIN_1_N 2
EXT_GPIN_2_P 3
EXT_GPIN_2_N 4
EXT_GPIN_3_P
5
EXT_GPIN_3_N 6
EXT_GPIN_4_P
7
EXT_GPIN_4_N 8
GPI 5-8
Definition RJ-45 pin
EXT_GPIN_5_P 1
EXT_GPIN_5_N 2
EXT_GPIN_6_P 3
EXT_GPIN_6_N 4
EXT_GPIN_7_P
5
EXT_GPIN_7_N 6
EXT_GPIN_8_P
7
EXT_GPIN_8_N
8
About 568A and 568B on an Ethernet connector
RJ-45
TIA/EIA-568A and -568B are two standards for connecting Category 3 and Category 5 wire to connectors. B oth are appropriate for
high s peed d ata, though 568 B is s omew hat more c omm on for installed wiring and 568A is more common in jumpers. There is no
performance advan tage either way. The only real difference between the two is the order in which the pairs are us ed (orange and
green).
Hold a c able as if to plug it into a wall jack, the locking tab down (contacts facing you). T he contacts are num bered 1-8 from left to
right. Here’s what you will see:
RJ-45 P in Number
(Left >Right copper
side)
568A 568B AES -1-8
1
White/Green White/Orange AES 1&2 +plus
2
Green Orange AES 1&2 +minus
3
White/Orange White/Green A ES 3&4 +plus
4 Blue Blue
AES 5&6 +m inu s
5
White/Blue White/Blue AES 5&6 +plus
6
Orange Green AES 3&4 +minus
7
White/Brown White/Brown AES 7&8 +plus
8Brown Brown
AES 7&8 +m inu s
150 R5906693 DP2K-E SERIES 19/06/2015
