5. Physical installation
90°
Inclined screen
Image 5-4
CAUTION: Th e DP2K -E series projector may tilt m aximu m 15° forward an d maximu m 5° bac kwards. No tilt is
allowed sideways.
The back feet of the projector can be turned out maxim um 125mm.
This correspond with a forward tilt of 12°
if the front foot is completely turned in.
Barco offers a pedestal for the DP 2K-E series projector. This universal p edestal allows you to ea sily tilt the
projectorforwardupto6°.
Use the tilt of the projector feet and the pedestal to get sufficient tilt.
26 R5906693 DP2K-E SERIES 19/06/2015
