8. ICMP
Detailed timings
@EDID
Color depth
(bpc)
Display Mode
(A, B)
Display Mode
2D / 3D
2048 x 2160 @ 60Hz (aka
4K@60Hz using A+B span)
8, 10 A+B sp an 2D + 3D
1920 x 1080 @ 60Hz
8, 10
Single
2D + 3D
Includes NTSC r efresh rates = (Hz*1000)/1001
Notes:
• DisplayMode = Single : is applicable to both DisplayPort A , and DisplayPort B input, se parately.
• DisplayMode = A +B : inputs DisplayPort A and DisplayPort B are combined to 1 larger image; in this cas e the 2 DisplayPort
links need to be genlocked ( = synchronous and in phas e).
• In all case s :
- Color S pace = RG B,
- Color S ampling = 4:4:4,
- Scan Type = progressive.
• Both N vidia and AM D G PU’s will not support color depths of 1 0 bits/color while in 3D-stereo mode.
• Some G raphical Cards may not perm it 10 bits/color at all v ideo timings, because of bandwidth restrictions.
• DisplayPort A and DisplayPort B autom atically detect:
- Active Pixels, and Active Lines
- Vertical Refresh
- 8 bits/color - 10 bits/color
- Frame locked
• Upscaled x2 if s maller than 50% of native DMD size, while maintaining aspect ratio (aka automatic 2K → 4K up-scaling on 4 K
projectors)
HDMI specifications
HDMI1.4b, including HDCP1.4
Video-timin gs :
• 4096 x 2160p at 24Hz
• 3840 x 2160p at 30Hz
• 3840 x 2160p at 25Hz
• 3840 x 2160p at 24Hz
• 1920 x 1080p at 60Hz
• 1280 x 720p at 60Hz
• 640 x 480p at 60Hz
• 800 x 600p at 60Hz
• 1024 x 768p at 60Hz
• 1400 x 1050p at 60Hz
• 1280 x 1024p at 60Hz
• 1024 x 768p at 60Hz
• 1280 x 960p at 60Hz
• 1920 x 1080p at 50Hz
• 1920 x 1080p at 24Hz
• 1920 x 1080p at 25Hz
• 1920 x 1080p at 30Hz
• 1280 x 720p at 50Hz
• 720 x 480p at 60Hz (VIC 2)
• 720 x 480p at 60Hz (VIC 3)
• 720 x 576p at 50Hz
Notes:
• Includes NTSC refresh rate = (Hz*1000)/1001
• Upscaled x2 if smaller than 50% of native DM D s ize, w hile maintaining aspect ratio (aka automatic 2K →4K up-scaling on 4K
projectors)
54
R5906693 DP2K-E SERIES 19/06/2015
