106 Encore Presentation System • User’s Guide
4. Controller Orientation
Controller Sections
3) Touch Screen
All menus and functions can be accessed in a variety of ways:
~ Touch the desired label on the Touch Screen itself (for example, the
{BORDER} or {SHADOW} buttons) to access the menu as indicated.
~ Press a Softkey that is directly adjacent to a label.
~ Use the top NAV knob to move the highlight to the desired line, then use
the
ADJ rotary knob (or the Joystick’s Z-Axis Knob) to adjust the value.
~ Touch a particular line to move the highlight to that line, then use the
ADJ rotary knob (or the Joystick’s Z-Axis Knob) to adjust the value.
~ Press a button in the System Keypad to jump directly to a top level
menu. Refer to the “
System Keypad“section on page 107 for details.
Please note the following important points regarding the adjustment of parameters:
• If you adjust a parameter using the ADJ knob or the Joystick’s Z-Axis Knob,
there is no
Enter button. Using this method, the modified function, parameter or
value is
immediately active in Preview.
• If you adjust a parameter using the Alphanumeric Keypad (on the Controller LC
only),
Enter must be pressed on the keypad itself for the value to take effect. In
Chapter 7, refer to the “
Using the Alphanumeric Keypad” section on page 288
for details.
