Background Input Setup Menu
pÜ~êÉÇ=_~ÅâÖêçìåÇ=jÉåì=cìåÅíáçåë
The figure below illustrates a sample BG Input Setup Menu, showing shared functions:
Figure 5-66. BG Input Setup Menu (sample)
The following functions are shared — regardless of the selected background type:
• Top Line — indicates the selected background button: BG_A or BG_B.
• Destination — displays the currently selected destination.
• ID — displays the ID(s) of the selected destination’s associated Processor. Note
that with wide screen destinations, the background for each Video Processor can
be individually adjusted.
• Type — selects the desired background type:
~ MATTE — a solid color can be used as the background. Refer to the
“
Background Menu Functions — Matte Type” section on page 220 for
menu details.
~ DVI — a digital graphic from a computer (or other DVI source) can be
used as the background. Refer to the “
Background (and DSK) Menu
Functions — DVI Type” section on page 222 for menu details.
~ Analog — an analog graphic from a computer (or other analog source)
can be used as the background. Refer to the “
Background (and DSK)
Menu Functions — Analog Type” section on page 223.
~ FG_1, FG_2 or FG_3 — a frame grab can be used as the background.
Refer to the “
Background (and DSK) Menu Functions — FG Type”
section on page 224 for menu details.
ID ALL
N
A
V
BG INPUT SETUP BG_A
DestinatDestination [ 1 ]
Type DVI
Note
Different backgrounds can be assigned to different
destinations.
