376 Encore Presentation System • User’s Guide
bK==^ééäáÅ~íáçå=kçíÉë
Encore Controller to Router Connections
båÅçêÉ=`çåíêçääÉê=íç=oçìíÉê=`çååÉÅíáçåë
This application note provides information on how to use RS-232 communications to
connect the Encore Controller (both the SC and LC models) to various routers and
peripheral equipment. All RS-232 connections to the Controller are made through the
controller's DB-9 EXT COMM port.
The following topics are provided in this application note:
• EXT COMM Pinouts
• Cable Connection — Straight Through
• Cable Connection — Null Modem
• Lantronix Ethernet to Serial Cable Connection
• Router Connection Table
Important
All Barco/ Folsom Routers can be connected to the Encore
Controller via Ethernet. This is the preferred connection
method.
