150 Encore Presentation System • User’s Guide
5. Menu Orientation
Output Menu
lìíéìí=jÉåì=cìåÅíáçåë
The following Output Menu functions are provided:
• Destination — indicates the destination on which you are currently working (as
selected on the
Destination Bus). If multiple destinations are active, you can
select one of them using this field.
• Format — sets the resolution and frame rate at which you want to drive your
projector(s). To minimize synchronization problems, select a frame rate that is
consistent with your input sources.
S If you are using 59.94 NTSC video inputs, run the output at the same rate in
order to reduce jutter artifacts.
After selecting a format, press
{APPLY FORMAT} to accept the selection. In
Appendix A, refer to the “
Input and Output Resolutions” section on page 352 for
details on all available resolutions.
• Color Space — sets the output’s color space, either RGB or YP
b
P
r
— per the
specifics of your projector.
• Press {GLCK} to display the Genlock Menu. Refer to the “Genlock Menu”
section on page 151 for details.
• Press {APPLY FORMAT} to accept a selected output format. In Appendix A, refer
to the “
Input and Output Resolutions” section on page 352 for details on all
available resolutions.
• Press {SETTINGS} to display the Settings Menu. Refer to the “Settings Menu”
section on page 152 for details.
• Press {TEST PATTERN} to display the Test Pattern Menu. Refer to the “Test
Pattern Menu” section on page 153 for details.
• Press {WIDE SCREEN} to display the Wide Screen Menu. Refer to the “Wide
Screen Settings Menu” section on page 154 for details.
lìíéìí=pìÄ=jÉåìë
The following sub menus can be accessed from the Output Menu:
• Genlock Menu
• Settings Menu
• Test Pattern Menu
• Wide Screen Settings Menu
Note
A selected Video Processor destination can be configured as
a single screen or multiple screens (in a wide screen
application). In this situation, all changes to the
Output
Menu
affect all Processors in a wide screen definition.
ScreenPRO-II destinations are single screen.
