Encore Presentation System • User’s Guide 227
5. Menu Orientation
Frame Grab Menu
~ For single screen and standard wide screen systems, selects one of
three “temp” frame stores (
FG_1, FG_2 or FG_3). Once selected, you
can capture into the selected frame store, save it to permanent memory,
or download a frame grab from permanent storage for use on-air.
~ For “stack” systems, selects one of six “temp” frame stores:
• For the “bottom” stack Processor, selects
BG_FG_1, BG_FG_2
or BG_FG_3).
• For the “top” stack Processor, selects
DSK_FG_1, DSK_FG_2
or DSK_FG_3).
• Capture Format — displays the output resolution. Encore always captures a full
screen image at the output resolution — regardless of the input resolution.
• Name — displays the name of the file in “temp” memory:
~ EMPTY — the frame store is completely empty, after a factory reset has
been performed.
~ UNSAVED_FG_[n] — the captured frame is unsaved.
~ SAVED_FG_[n] — the frame is saved in permanent memory, but it has
not been assigned a custom name.
~ [NAME] — the frame is saved in permanent memory with a custom
name, up to 23 characters in length. Spaces are allowed.
• Format — displays the resolution of the frame in permanent memory.
• Press {NAME} to display the Frame Grab Name Menu. Refer to the “Frame
Grab Name Menu” section on page 228 for details.
• Press {ERASE} to display the Frame Erase Menu. Refer to the “Frame Erase
Menu” section on page 229 for details.
• Press {CAPTURE} to capture a frame into the selected “temporary” frame store.
Once pressed, the screen indicates that the frame is being captured.
• Press {SAVE} to display the Frame Save Menu. Refer to the “Frame Save
Menu” section on page 230 for details.
• Press {DELETE} to display the Frame Delete Menu. Refer to the “Frame Delete
Menu” section on page 231 for details.
• Press {RECALL} to display the Frame Recall Menu. Refer to the “Frame Recall
Menu” section on page 232 for details.
In Chapter 7, see the “
Working with Frame Grabs” section on page 332 for details.
cê~ãÉ=dê~Ä=pìÄ=jÉåìë
The following sub menus can be accessed from the Frame Grab Menu:
• Frame Grab Name Menu
• Frame Erase Menu
• Frame Save Menu
• Frame Delete Menu
• Frame Recall Menu
