54 Encore Presentation System • User’s Guide

3. Hardware Installation

Installation

fåëí~ää~íáçå

Detailed installation procedures are provided for the Encore configurations listed below.

Select the desired configuration, and follow all procedures as listed in the section:

• Single Screen Configuration

• Triple Screen Configuration

• Wide Screen Configuration

• Wide Screen Configuration Plus Wide Screen Preview

• Single Screen Stack Configuration

• Wide Screen Stack Configuration
