^K==péÉÅáÑáÅ~íáçåë
Output Specifications
lìíéìí=péÉÅáÑáÅ~íáçåë=
The table below lists Encore Presentation System output specifications.
Table A-2. Encore Video Processor Output Specifications
Output Parameter Specification
Preview Output Analog Outputs RGBHV / RGBS / RGsB, YPbPr video (SD or HD), on 15-pin
HD connectors
DVI Output Per DDWG 1.0 on DVI-I connector
Program Output 1
Analog Outputs RGBHV / RGBS / RGsB, YPbPr video (SD or HD), on 15-pin
HD connectors
DVI Output Per DDWG 1.0 on DVI-I connector
Optional HDSDI
Output
Per SMPTE 259M-C (NTSC / PAL resolution) SMPTE 292M
(HDTV) on BNC connector (Program Out)
Program Output 2
Function This output can be programmed to serve as a second
buffered program output or a monitoring program output
Analog Outputs RGBHV / RGBS / RGsB, YPbPr video (SD or HD), on 15-pin
HD connectors
DVI Output Per DDWG 1.0 on DVI-I connector
Optional HDSDI
Output
Per SMPTE 259M-C (NTSC / PAL resolution) SMPTE 292M
(HDTV) on BNC connector (Program Out)
Output Resolutions
• Computer Resolutions VGA (640 x 480) through
UXGA (1600 x 1200)
• HDTV Resolutions up to 1920 x 1080 (720p,1080I,
1080p)
• 2048 x 1080 (Digital Cinema format)
• Plasma Display Resolutions
Delay
50Hz 30ms max.
60Hz 25ms max.
