Encore Presentation System • User’s Guide 265
6. System Setup
Genlock Setup
dÉåäçÅâ=pÉíìé
Encore system setup: Step 14
S Prerequisites — Ensure that you are familiar with the Genlock Menu. In
Chapter 5, refer to the “
Genlock Menu” section on page 151.
In this procedure, you will set up Genlock for each destination.
Use the following steps to set up Genlock:
1. In the System Keypad, press OUTPUT to display the Output Menu.
2. On the Destination Bus, select the destination that you want to configure.
3. Press {GLCK} to display the Genlock Menu.
4. For all types of destinations, set the genlock source on the Source line. Choose
between
Black Burst, CSync or None.
5. For ScreenPRO-II destinations only, verify the setting of the ScreenPRO-II’s
Termination Switch on the
Termination line. The menu prompts you how to
change this
physical switch on the ScreenPRO-II itself, if required.
6. Press {BACK} to return to the Output Menu.
7. Repeat from step 2 to set additional destination genlock types.
8. In the System Keypad, press {SAVE} to save the new configuration in memory.
14
Note
When you select the Source, the Type line automatically
displays the type of genlock provided.
