Encore Presentation System • User’s Guide 167
5. Menu Orientation
System Menu
• VP (SP) to Add — lists all available Processors or ScreenPRO-IIs that can be
assigned to the destination. If a Processor is currently assigned to another
destination, it will not appear in the list.
Processors are identified by ID.
• VP (SP) to Remove — lists all assigned Processors or ScreenPRO-IIs that can
be removed from the destination.
Processors are identified by ID.
• Routing Mode — if Single Screen SP is selected on the “Type” line, the Routing
Mode
line appears which enables you to set the ScreenPRO-II’s routing mode —
either
Internal or External. This function instructs the system how sources are
used on the assigned ScreenPRO-II.
• At the bottom of the menu, the Status section dynamically lists the Processor IDs
assigned to the current destination.
• Press {ADD} to add the selected Processor or ScreenPRO-II (on the VP [SP] to
Add
line) to the current destination configuration.
• Press {REMOVE} to remove the selected Processor or ScreenPRO-II (on the VP
[SP] to Remove
line) from the current destination configuration.
• Press {REMOVE ALL} to remove all Processors from the current destination.
Note
When an Aux, ImagePRO Aux or PrePRO-II Aux destination
is selected, the {
AUX SETUP} button appears, which enables
you to set the parameters of the Aux destination. Refer to the
“
Aux Setup Menu” section on page 168 for details.
Note
If you have defined a destination as a Wide Screen,
preliminary wide screen setup information will be sent to the
Video Processors when you exit this menu.
