Encore Presentation System • User’s Guide 123
4. Controller Orientation
Controller Sections
Preview OSD —
Clear Layer — press to remove the currently selected (blinking) layer from Preview — in
preparation for transitioning it off Program. The button can be used to clear backgrounds,
PIPs, Keys and the DSK. In Chapter 7, refer to the “
Clearing Layers from Program”
section on page 305 for instructions.
All — press All + Clear Layer (or Clear Layer + All) to remove all layers from Preview —
in preparation for transitioning them all off Program. In Chapter 7, refer to the “
Clearing
Layers from Program” section on page 305 for instructions.
Freeze — press to freeze a PIP or Key.
• In Split Mode, PIPs or Keys can be frozen on both Program and Preview.
• In Mix Mode, PIPs or Keys can only be frozen on Preview — prior to transitioning
them to Program.
In Chapter 7, refer to the “
Using Freeze” section on page 309 for instructions.
Preview
OSD
Note
The Preview OSD function is currently not implemented.
Clear
Layer
All
Freeze
