Encore Presentation System • User’s Guide 169
5. Menu Orientation
System Menu
When an ImagePRO Aux or PrePRO-II Aux destination “type” is selected on the
Destination Setup Menu, the Aux Setup Menu appears in this form:
Figure 5-26. Aux Setup Menu — ImagePRO Aux Destination (sample)
The following functions are provided:
• Top Line — displays the type of Aux destination and its selected number.
• Source Mapping — two selections are available:
~ Input Patch — maps Aux sources according to how your inputs are
patched to buttons in the console’s
Source Selection section.
~ Direct Map — maps Aux sources according to how your inputs are
connected to the router.
• ImagePRO ID (or PrePRO-II ID) — selects the ID of the ImagePRO or PrePRO-II,
to which you want to route Aux sources.
• Analog Router Name — selects the router from which analog sources will be
routed to the ImagePRO or PrePRO-II.
• Analog Router Output — selects the specific router output designated as Aux
(as assigned on the router’s
Output Patch Menu).
• ImagePRO Input (or PrePRO-II input) — selects the ImagePRO or PrePRO-II
input to which the router output is connected.
• SDI Router Name — selects the router from which SDI sources will be routed to
the ImagePRO or PrePRO-II.
• SDI Router Output — selects the specific router output designated as Aux (as
assigned on the router’s
Output Patch Menu).
• ImagePRO Input (or PrePRO-II input) — selects the ImagePRO or PrePRO-II
input to which the router output is connected.
• DVI Router Name — selects the router from which DVI sources will be routed to
the ImagePRO. (Not applicable to PrePRO-II Aux destinations.)
• DVI Router Output — selects the Aux router output (as assigned on the router’s
Output Patch Menu). (Not applicable to PrePRO-II Aux destinations.)
B
A
C
K
A
D
J
AUX SETUP
Source Mapping Input Patch
ImagePRO ID:
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
RESET
DEST_2
17
ANALOG Router Name MATRIXPRO1
ANALOG Router Output 7
ImagePRO Input:
SDI Router Name MATRIXPRO2
SDI Router Output 8
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1
N
A
V
