276 Encore Presentation System • User’s Guide
6. System Setup
DSK Setup
8. To configure an Analog source as the DSK:
a. Ensure that your analog source is properly connected to the Video
Processor chassis. In Appendix A, refer to the “
DVI-I Connector
Pinouts” section on page 347 for pinout details.
b. Scroll to the DSK Input line and select the input connector from which
the DSK source is pulled.
c. Scroll to the Type line and select Analog.
d. Set the analog source’s format:
• Press
{FORCE ACQUIRE}, or ...
• To manually set the source’s resolution, select the desired
format on the
Format line, then press {APPLY FORMAT}.
e. (Optional) Adjust H Offset, V Offset, Contrast, Brightness, Sizing and
Color Balance as required.
f. Press {SAVE}.
9. Press {KEY} to return to the DSK Adjustment Menu.
10. On the Key Type line, select the type of key desired (Luma or Color).
11. Adjust key parameters as required:
~ For a Luma Key, adjust Invert Mode, Clip, Gain, Opacity and Fill
Source
for the optimum visual key.
~ For a color key, pick the desired color, then adjust Red, Green and Blue
Color
, Threshold, Mask and Opacity.
12. When your DSK is fully adjusted, press SAVE in the System Keypad.
Note
Analog DSKs cannot be configured on ScreenPRO-II
destinations.
