74 Encore Presentation System • User’s Guide
3. Hardware Installation
Installation
10. ScreenPRO-II Connections — if your system includes one (or more)
ScreenPRO-II units as unique destinations, you can configure the ScreenPRO-II
for internal or external source routing:
a. When External routers are used, connect two outputs from an Analog
router to
any two HD-15 inputs on the ScreenPRO-II. An SDI router
can also be connected to BNC inputs
1 and 2. During setup, these
specific patches will be defined using the
Output Patch Menu.
b. When Internal routing is used, connect Analog sources to inputs 1 - 8 on
the HD-15 connectors, and SDI sources to BNC inputs
1 and 2. During
setup, these patches will be defined using the
Input Patch Menu.
11. Output Connections — all output monitor and projector connections originate
from the “
top stack” Processor:
a. Connect the analog or digital Preview Output to the input of the
associated Preview Monitor.
b. Connect the analog or digital Program 2 Output to the input of the
associated Program Monitor.
c. Connect the analog or digital Program 1 Output to the input of the
associated projector.
d. (Optional) If your Processors are configured with the HD/SDI output,
connect the
Program Out HD/SDI connector to an SDI or HDTV monitor
as required, or to the proper video distribution equipment.
e. If you elect to output in an interlaced format (e.g., 1920 x 1080i), connect
the top stack’s
H Sync Output signal (located on the Program 2 Out
Analog
connector) to the Genlock input on the bottom stack.
12. Aux Destinations — you can configure three types of Aux destinations: Aux
(monitors), ImagePRO Aux and PresentationPRO-II Aux. Refer to Appendix D,
“
Working With Destinations” on page 367 for interconnection details.
13. Power Connection — connect AC power cords to all Encore and peripheral
equipment, and then to AC outlets.
14. Tally Connection — the Controller provides one 25-pin D connector for issuing
“relay closure” commands to external devices. Eight circuits are provided. In
Appendix A, refer to the “
Tally Connector” section on page 351 for details.
15. System ID — Using the Unit ID Selector, set the ID of the bottom stack
Processor to
1. Set the ID of the top stack Processor to 2.
16. Power On — all power on instructions are covered in Chapter 6.
With all connections made, continue with Chapter 4, “
Controller Orientation” on page 97.
Note
This output will only work if the selected output resolution is a
valid SDI or HD/SDI format.
Note
Using a (customer supplied) VGA to 5xBNC breakout cable,
the
H Sync Output line is typically a white or gray cable.
Important
The ID of the bottom stack Processor must always be lower
than the ID of the top stack Processor.
