R5906167 /00 ImagePRO–4K Video Processor
30
LED Setup key
1. Press the LED Setup menu key to enter the LED Setup.
2. Scroll through the LED Setup menu to select the Aux channel, the wall sizing, and the image
sizing.
3. Select Save All to save your settings.
TEST PATT key
1. Press the TEST PATT menu key to enter the Test Pattern menu.
2. Scroll through the Test Pattern menu to select the Aux channel and the type of test pattern
and to set the AOI Raster Box, the Output Raster Box, and the Diagonal Motion on or off.
The test-pattern types are:
• Off
• Horizontal Ramp
• Vertical Ramp
• 100% Color Bars
• 16x16 Grid
• 32x32 Grid
• Burst
• 75% Color Bars
• 50% Gray
• Horizontal Steps
• Vertical Steps
• White
• Black
• SMPTE Bars
• H Alignment
• V Alignment
• HV Alignment
• Circle Alignment
• Red
• Green
• Blue
Setup and operation
