Barco Thor series Installation Manual

R5906788-03 Thor series88
SMPTE Standard
Source
Resolution
Frame Rate
Display Rate Scan Type
SMPTE 274M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
23.976
24
25
29.970
30
Progressive
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
23.976
24
25
29.970
30
Segmented frame
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M 1920 x 1080 25
29.970
30
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
Standard HD-SDI (2 × SMPTE 292M) formats
2
SMPTE Standard
Source
Resolution
Frame Rate
Display Rate Scan Type
SMPTE 292M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
47.952
48
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
SMPTE 292M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
47.952
48
50
59.940
60
Segmented frame
Y Cb Cr 4:2:2 10-Bit
The standard HD-SDI interfaces support the Y Cb Cr colorspace (both legal and full range) using 4:2:2 color
subsampling.
The Dual-Link HD-SDI interface can be used to carry a single 4:4:4 image, having a color depth of 10 or 12 bit
per component. Both RGB (XYZ) and Y Cb Cr color spaces are supported.
SMPTE 424M 3G HD-SDI 2.970 Gb/s SIGNALS
3G HD-SDI (SMPTE 425) formats
