Operation and Control System
A: R82GB0FA.PMD
B: R82DE0FA.P65
E: 080403 / T. Weiß
G: 200103 / TCS
Section 5.5
Page 25
?
Conveyor commands
Conveyor ON
Conveyor OFF
Conveyor ON/OFF
Conveyor ON 1.2s
Conveyor is switched on and deactivated after
X.X seconds.
WaCON Signal ON
WaCON Signal OFF
At WaCON signal ON, the system waits until the
input signal indicates ””Conveyor full””, logic “”0””
and the output signal indicates ””Conveyor ON””,
logic ""0””. At WaCON signal OFF, both signals
must be logic ””1””.
WaPos1 Signal ON
WaPOS1 Signal OFF
The system waits for the ””Position space free””
input signal. OFF indicates that the position is
free. ON indicates that it is occupied.
IfCON ON L5
IfCON OFF L5
At CON ON (Conveyor is not full and
deactivated), the system jumps to Label 5. At
CON OFF the conveyor is full and activated.
If POSfree
If POSNfree
At ””Position free”” and ””Position not free”” the
system jumps to Label 5.
Action Switch Goto Time
Conveyor
ON/OFF
Band ein
X.X s
WaCONV ON
WaCONV OFF
WaPOS ON
WaPOS OFF
If CONV on
Label 1-10
If CONV off
Label 1-10
If POS free
Label 1-10
If POS n free Label 1-10
R8B2_GB139.XLS
To Next Page
