Baumuller b maXX 5000 Series User Manual

Connections on the front side
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
172
of 328
7.15
Pin assignment X1
Pin No. Assignment
1 dig. input/output GND 24 V
2 digital input Inhibit input
1)
BM50XX-XX00
input is high active,
exp
ects NO contact
BM50XX-XX01
input is low active,
expects NC contact
3 digital input Quick discharge of 
DC link voltage
4 digital input Reset
5 digital output Error
6 digital output Ready-to-operate
1)
An external brake resistor can have a thermo switch. When the external switch is closed or opened the LED
H4 (over temperature) lights up and the device state changes to error state. All thyristors are disabled, on the
signal bus is error sent.
When the thermo switch changes state to initial condition again
the error has to be acknowledged by reset
(X1:4). Refer to ZError
acknowledgment of BM50XX– on page 238.
