LED
POWERLINK
®
.
Type code
BM5XXX-XXXX-XXXX-04XX
Naming on the 
front plate
H31 (green) X3 Link / Act Off: No connection
On: Connection
Blinking: Data transfer
H32 (yellow) ERROR Off: NMT_CT3, NMT_CT7, NMT_GT2
On: NMT_CT11, NMT_GT6
Blinking: Configuration error (e.g. address seting)
H41 (green) X4 Link / Act Off: No connection
On: Connection
Blinking: Data transfer
H42 (green) STATUS Off: NMT_GS_OFF, NMT_GS_INITIALISATION,
NMT_CS_NOT_ACTIVE
50 ms off /
50 ms on: NMT_CS_BASIC_ETHERNET
200 ms on /
1 s off: NMT_CS_PRE_OPERATIONAL_1
2 x 200 ms on /
1 s off: NMT_CS_PRE_OPERATIONAL_2
3 x 200 ms on /
1 s off: NMT_CS_READY_TO_OPERATE
On: NMT_CS_OPERATIONAL
200 ms on /
200 ms off: NMT_CS_STOPPED
Meaning Blinking pattern
