Appendix A: Specifications 137
SIGMA Spectrum Infusion System Pump Operating Software Version 8.00
Operator’s Manual For Use With MDL Version 8.0
Logging Memory
■ While not in use, the Pump’s memory will retain the last
programmed setup screen for 24 hours.
NOTE: Multi-step and cyclic modes are retained until using the
clear program soft key.
■ The Pump history log can be filtered to only display the logged
system error events or the logged drug error events.
■ Minimum 4,500 Event Log Capacity.
NOTE: An event is any user-confirmed data entered into the Pump.
Once the maximum log file size is reached, the data for
each new event replaces the data for the oldest event (the
data for the oldest event is lost).
Low-Flow Continuity The maximum period of no-flow is 90 seconds at a flow rate of
0.5 mL/hr.
Maximum Allowable pressure while in
downstream occlusion
207 kPa (30 psi)
Downstream Occlusion Pressure Adjustable
■ Low, 41 kPa ±27 kPa (6 ±4 psi)
■ Medium, 89 kPa ±41 kPa (13 ±6 psi)
■ High, 131 kPa ±62 kPa (19 ±9 psi)
Operational Conditions With Standard Battery
■ Operating temperature: 15.6 to 32.2°C (60 to 90°F), 20 to 90%
relative humidity non-condensing
With Wireless Battery Module
■ Operating temperature: 15.6 to 26.7°C (60 to 80°F), 20 to 90%
relative humidity non-condensing
WARNING Environmental Limits
Use of the SIGMA Spectrum Infusion System outside the
environmental limits, noted in Appendix A as “Operational
Conditions” may cause performance issues with the SIGMA
Spectrum Infusion System, including but not limited to: under or
over infusion, inability to detect upstream or downstream
occlusions, inability to charge battery, and/or decreased battery
life.
Storage and Packing Conditions With Standard Battery
■ Storage temperature: -10 to +49°C (14 to 120°F),
10 to 90% relative humidity non-condensing
With Wireless Battery Module
■ Storage temperature: -10 to +49°C (14 to 120°F),
10 to 90% relative humidity non-condensing
Specification Description
