138 Appendix A: Specifications
Manual 41018v0800 SIGMA Spectrum Infusion System
Revision B Operator’s Manual
Overall Size (Pump) With Standard Battery
■ Without IV pole clamp:
Height 14.7 cm (5.8 in)
Width 10.6 cm (4.2 in)
Depth 6.35 cm (2.5 in)
■ With IV pole clamp:
Height 14.7 cm (5.8 in)
Width 16.25 cm (6.4 in)
Depth 11.93 cm (4.7 in)
With Wireless Battery Module
■ Without IV pole clamp:
Height 16 cm (6.3 in)
Width 10.6 cm (4.2 in)
Depth 6.35 cm (2.5 in)
■ With IV pole clamp:
Height 16 cm (6.3 in)
Width 16.2 cm (6.4 in)
Depth 11.93 cm (4.7 in)
Pumping Mechanism Linear peristaltic
Single Fault Condition A maximum bolus of 0.56 mL may be generated as a result of a
Single Fault Condition (a failure of the SIGMA Spectrum Infusion
Pump, which stops the Pump motor and results in an alarm).
Timekeeping Real Time Clock, battery-backed, 10-year life
NOTE: Clock is set to GMT.
Total Volume 0.1 to 9999 mL with 0.1 mL increments from 0.1 to 99.9 mL and
1.0 mL increments from 100 to 9999 mL
Volumetric Accuracy Accuracy is based on volume collected over one hour using
compatible Baxter Standard IV Sets.
.
Specified accuracy is maintained on Baxter Standard IV Sets for up
to 96 hours (maximum 12 liters). See “Compatible IV Sets” on
page 123.
Specification Description
Rate Accuracy
0.5 – 1.9 mL/hr ±0.1 mL/hr
2.0 – 999 mL/hr ±5%
