Holder Type
Place Holder Type
Tray Mat (Optional)
Doctor Control Panel
Handle
Doctor Instruments Holder
(Holder Type)
Tray Mat (Optional)
Doctor Control Panel
Handle
Doctor Instruments Holder
(Place Holder Type)
Doctor Unit Section
12
OVERVIEW AND MAJOR COMPONENTS
Cuspidor Maintenance
Panel
Solid Collector
Assistant Control Panel
Assistant Instruments
Holder
Assistant Arm
Cuspidor Control Panel
Sensor Cupfiller (optional)
Height Adjustable Assistant Arm (Optional)
Lock release button
Cuspidor Unit Section
