OVERVIEW AND MAJOR COMPONENTS
Water Master Valve
Drain Valve
Water Pressure Gauge
Air Pressure Gauge
Fuse Holder
Junction Box Section
Water main valve (inside junction box)
Turn clockwise to open and counter-clockwise to close.
Drain valve
Drains the water collected at the air filter on the
main water supply line.
Fuse holder
• The main fuse of units is built-in.
• Turn off the main switch when replacing the fuse.
• The capacity of the fuse displays it on the left side of
the fuse holder.
13
Height Adjustable Assistant Arm
Lock release button
Assistant Holder
Vacuum Roller (Optional)
Solid Collector
Vac Pac Section (Vacuum Package)
To Next Page
