LR2000 Programming Manual V1.2
Control character
HRI
character
Control character
HRI
character
ASCII
Hex
Decimal
ASCII
Hex
Decimal
NUL
00
0
■U
DEL
10
16
■P
SOH
01
1
■A
DC1
11
17
■Q
STX
02
2
■B
DC2
12
18
■R
ETX
03
3
■C
DC3
13
19
■S
EOT
04
4
■D
DC4
14
20
■T
ENQ
05
5
■E
NAK
15
21
■U
ACK
06
6
■F
SYN
16
22
■V
BEL
07
7
■G
ETB
17
23
■W
BS
08
8
■H
CAN
18
24
■X
HT
09
9
■I
EM
19
25
■Y
LF
0A
10
■J
SUB
1A
26
■Z
VT
0B
11
■K
ESC
1B
27
■A
FF
0C
12
■L
FS
1C
28
■B
CR
0D
13
■M
GS
1D
29
■C
SO
0E
14
■N
RS
1E
30
■D
SI
0F
15
■O
US
1F
31
■E
DEL
7F
127
■T
When CODE128 (m = 73) is used:
 When using CODE128 in this printer, take the following points into account for data
transmission:
① The top of the bar code data string must be the code set selection character
(CODE A, CODE B, or CODE C), which selects the first code set.
② Special characters are defined by combining two characters "{" and one character.
The ASCII character "{" is defined by transmitting "{" twice consecutively.
Specific character
Transmit data
ASCII
Hex
Decimal
SHIFT
{S
7B, 53
123,83
CODE A
{A
7B, 41
123,65
CODE B
{B
7B,42
123,66
CODE C
{C
7B,43
123,67
FNC1
{1
7B,31
123,49
FNC2
{2
7B,32
123,50
FNC3
{3
7B,33
123,51
